Aprilog PLCC Device Programming Adapters

20 Pins 28 Pins 32 Pins 44 Pins 52 Pins 68 Pins 84 Pins Part Number   20 Pin PLCC Programming Adapters    Price Shopping Cart 20PL-8D6-ZAD-17C 20 Pin PLCC Programming adapter for serial EEPROMs in 20 lead PLCC packages. Dead-bug insertion autoeject socket, i.e. The component is inserted upside down with the cut corner to the right. For plastic packages only. This PLCC programming adapter is wired to accommodate Xilinx, Atmel and pin compatible serial EEPROMs from 1736 to 17C010 and 17C010A. The adapter works on any programmer which supports these serial EEPROMs in an 8 pin DIP package Dead Bug (Legs up) Insertion Plastic PLCC Package Type 20 Pins PLCC to 8 Pin DIP DIP rows are 600 mils apart For Xilinx, Atmel and pin compatible serial EEPROMs from 1736 to 17C010 and 17C010A. Compatible with any programmer supporting the listed EEPROMs in an 8-pin DIP package $100.00 20PL-D6-ZAD 20 Pin PLCC Programming adapter for serial EEPROMs in 20 lead PLCC packages. Dead-bug insertion autoeject socket, i.e. The package is inserted upside down with the cut corner to the right. Accepts plastic packages only. This programming adapter is wired one-to-one (generic) and is commonly used to program PALs such as 16V8 and other devices with one-to-one pin assignment between PLCC and DIP pins. Dead Bug (Legs up) Insertion Plastic PLCC Package Type 20 Pins PLCC to 20 Pin DIP Pins are wired one-to-one DIP rows are 600 mils apart Wired one-to-one from DIP to PLCC pins. Typically used for devices wired one-to-one Common application is for PALs such as 16V6 from Cypress, Atmel, Micrel, Lattice $100.00 Part Number   28 Pin PLCC Programming Adapters    Price Shopping Cart 28PL-24D6-3-ZAL 28 Pin PLCC Programming adapter for 22V10, PLCC having no connection on pins 1, 8, 15, 22, and pin compatible devices in 28 lead PLCC packages. The adapter converts 28 pin PLCC package to 24 pin DIP plug. This PLCC progamming adapter works on any programmer which supports compatible PAL devices in a 24 pin DIP package. Plastic PLCC Package Type 28 Pins PLCC to 24 Pin DIP No connection to pins 1, 8, 15, & 22 DIP rows are 600 mils apart Common application is for GALs such as 22V10 and pin compatible devices from Lattice and Atmel Compatible with any programmer supporting the 22V10 or pin compatible device in a 24 pin DIP package $110.00 28PL-24D6-5-ZAL 28 Pin PLCC Programming adapter for PAL devices, PLCC having no connection on pins 1, 10, 15, 21, and pin compatible OTP or FLASH devices in 28 lead PLCC packages. The adapter converts 28 pin PLCC package to 24 pin DIP plug. This PLCC progamming adapter works on any programmer which supports pin compatible OTP or FLASH devices in a 24 pin DIP package. Plastic PLCC Package Type 28 Pins PLCC to 24 Pin DIP No connection to pins 1, 10, 15, & 21 DIP rows are 600 mils apart Common application is for OTP or FLASH memory Compatible with any programmer supporting OTP or FLASH devices with no connects on the listed PLCC pins $110.00 28PL-24D6-ZAL-751 28 Pin PLCC Programming adapter for NXP - Philips, 87C750, 87C751, and pin compatible devices in a 28 lead PLCC package. This PLCC progamming adapter works on any programmer which supports pin compatible devices in a 24 pin DIP package. Plastic PLCC Package Type 28 Pins PLCC to 24 Pin DIP For NXP - Philips, 87C750, 87C75 & compatible devices DIP rows are 600 mils apart Compatible with any programmer supporting NXP - Philips 87C750 and 87C751 or a pin compatible device in a 24-pin DIP package $110.00 28PL-D6-ZAL 28 Pin PLCC to DIP adapter with all pins wired one-to-one. This progamming adapter is used mainly for PALs, NXP - Philips 87C752 microcontroller, some memories, etc. Plastic PLCC Package Type 28 Pins PLCC to 28 Pin DIP Pins are wired one-to-one DIP rows are 600 mils apart Compatible with any programmer supporting NXP - Philips 87C752 & compatible devices, PAL and memory devices in 24-pin DIP packages Replaceable ZIF socket is Yamaichi IC120-0284-108 $110.00 Part Number   32 Pin PLCC Programming Adapters    Price Shopping Cart 32PL-28D6-ZO 32 Pin PLCC This progamming adapter is used mainly for 27C256, 27C512 memories, and pin compatible devices. Plastic 32 pin PLCC Package Type Compatible PLCC Package Drawing Live bug programming. Socket is plug-in replaceable. The replacement ZIF auto-eject socket is a Yamaichi IC120-0324-309 32 Pins PLCC to 28 Pin DIP Pins are wired sequentially starting with PLCC pin 2 to DIP pin 1 and so on to DIP 28. PLCC Pins 1, 12, 17, 26 are not connected DIP pins are 25 mil square wire wrap DIP rows are 600 mils apart Compatible with any programmer supporting 27C256, 27C512 memories, and pin compatible devices. $160.00 32PL-D6-ZO 32 Pin PLCCto 32 pin DIP. All adapter pins are wired one-to-one. 32 Pin PLCC to 32 Pin DIP Compatible PLCC Package Drawing Live bug programming. DIP rows are 600 mils apart DIP pins are 25 mil square wire wrap Wired one-to-one from DIP pin 1 to PLCC pin 1 & so on to 32. Compatible with any programmer supporting 1 to 4Mb EPROM and flash memories, etc. $160.00 Part Number      Price Shopping Cart AD-44-PL-44DIP 44 Pin PLCC Manufactured for ICE Technology LV series device programmers. Plastic PLCC Package Type 44 Pins PLCC to 44 Pin DIP DIP rows are 600 mils apart $140.00 AD-44PL-8751 44 Pin PLCC for 87C51 microcontroller Manufactured for ICE Technology LV series device programmers. Plastic PLCC Package Type 44 Pins PLCC to 44 Pin DIP DIP rows are 600 mils apart $140.00 44PL-40D-2-ZAL 44 Pin PLCC Programming adapter for 16-bit wide memories such as 27C1024, 2048, 4096 and pin compatible devices. No connection on pins 1, 13, 23, 33, and pin compatible PAL devices in 28 lead PLCC packages. The adapter converts 44 pin PLCC package to 40 pin DIP plug. Plastic PLCC Package Type 44 Pins PLCC to 40 Pin DIP For parallel memory such as 27C1024, 27C2048, 27C4096 No connection on PLCC pins 1, 13, 23, 33 DIP rows are 600 mils apart $140.00 44PL-40D-ZO-8051 44 Pin PLCC Programming adapter for 8xC51 microcontrollers and pin compatible devices in 44 lead PLCC package. Pins 1, 12, 23, 34 are not connected. The adapter converts 44 pin PLCC package to 40 pin DIP plug. Plastic PLCC Package Type 44 Pins PLCC to 40 Pin DIP For 8xC51 microcontrollers 1, 12, 23, 34 DIP rows are 600 mils apart Compatible with any programmer supporting to 8xC51 microcontroller series. $140.00 44PL-40D-ZO-ATmega 44 Pin PLCC Programming adapter for Atmega 44 pin PLCC components. Pins 1, 23, 24 & 44 are not connected. The adapter converts 44 pin PLCC package to 40 pin DIP plug. Plastic PLCC Package Type 44 Pins PLCC to 40 Pin DIP For Atmega pin compatible devices No connection on pins 1, 23, 24 & 44 DIP rows are 600 mils apart $140.00 44PL-40D-ZO-8535 44 Pin PLCC Programming adapter for 44-PLCC Atmel 90S8535 and 90S4434 and pin compatible devices in 44 lead PLCC package. Pins 17, 18, 38,39 are not connected. The adapter converts 44 pin PLCC package to 40 pin DIP plug. Plastic PLCC Package Type 44 Pins PLCC to 40 Pin DIP For Atmel 90S8535 and 90S4434 and pin compatible devices No connection on pins 17, 18, 38, 39 DIP rows are 600 mils apart $140.00 44PL-40D-ZO-PIC16C 44 Pin PLCC Programming adapter for 44-PLCC Microchip PIC16C64, all PIC16Cxxx, PIC16Fxxx, PIC18Cxxx, PIC18Fxxx and pin compatible devices in 44 lead PLCC package. Pins 1, 17, 28,40 are not connected. The adapter converts 44 pin PLCC package to 40 pin DIP plug. Plastic PLCC Package Type 44 Pins PLCC to 40 Pin DIP Common application is for Microchip PIC16C64, all PIC16Cxxx, PIC16Fxxx, PIC18Cxxx, PIC18Fxxx and pin compatible devices No connection on pins 1, 17, 28,40 DIP rows are 600 mils apart $140.00 44PL-40D-ZO-PIC17C 44 Pin PLCC Programming adapter for Microchip PIC17C42, PIC17C42A, PIC17C43, PIC17C44 and pin compatible devices in 44 lead PLCC package. Pins 2 is not connected. The adapter converts 44 pin PLCC package to 40 pin DIP plug. Plastic PLCC Package Type 44 Pins PLCC to 40 Pin DIP For Microchip PIC17C42, PIC17C42A, PIC17C43, PIC17C44 and pin compatible devices No connection on pin 2 Pins 1 and 44 are joined and so are pins 11, 12 and 33, 34 DIP rows are 600 mils apart $140.00 Part Number      Price Shopping Cart 52PL-40D-ZL-DS87C530   52 Pin PLCC Programming adapter for Dallas Semiconductor DS87C530, (Maxim IC), microcontroller in 52 lead PLCC package. Clamshell ZIF Socket For Dallas Semiconductor - Maxim IC DS87C530 Plastic PLCC Package Type 52 Pins PLCC to 40 Pin DIP Clamshell ZIF Socket DIP rows are 600 mils apart $180.00 52PL-40D-ZAL-AT89C5131   52 Pin PLCC Programming adapter for Atmel AT89C513 microcontroller in 52 lead PLCC package. Auto-eject ZIF Socket For Atmel AT89C5131 Plastic PLCC Package Type 52 Pins PLCC to 40 Pin DIP Auto-eject ZIF Socket DIP rows are 600 mils apart $180.00 52PL-40D-ZAL-DS87C530   52 Pin PLCC Programming adapter for Dallas Semiconductor DS87C530 microcontroller in 52 lead PLCC package. Auto-eject ZIF Socket For Dallas Semiconductor - Maxim IC DS87C530 Plastic PLCC Package Type 52 Pins PLCC to 40 Pin DIP Auto-eject ZIF Socket DIP rows are 600 mils apart $250.00 52PL-PL-ZLPHC11 52 Pin PLCC Programming adapter for NXP - Motorola 68HC11 microcontroller in 52 lead PLCC package. Clamshell ZIF Socket. PLCC plug adapter provides programming capability with in-circuit emulators or circuit boards with a PLCC socket. For NXP Motorola 68HC11 Plastic PLCC Package Type 52 Pins PLCC to 52 pin PLCC socket Clamshell ZIF Socket $250.00 Part Number   68 Pin PLCC Programming Adapters    Price Shopping Cart 68PL-40D-ZAL-PIC16C923 68 Pin PLCC Programming adapter for Microchip PIC PIC16C923, PIC16C924, PIC16C925, PIC16C926 microcontrollers. Auto-eject ZIF Socket For Microchip PIC16C923, PIC16C924, PIC16C925, PIC16C926 Plastic PLCC Package Type 68 Pins PLCC to 40 Pin DIP Auto-eject ZIF Socket Staggered DIP rows are 500 and 600 mils apart $180.00 68PL-40D-ZAL-PIC17C752 68 Pin PLCC Programming adapter for Microchip PIC 17C752 & 17C756A microcontrollers. For parallel programming. All 40 signals used on PIC17C42 are brought out to the DIP plug. Auto-eject ZIF Socket For Microchip PIC17C752 & PIC17C756A Plastic PLCC Package Type 68 Pins PLCC to 40 Pin DIP Auto-eject ZIF Socket DIP rows are 600 mils apart $180.00 68PL-40D-ZL-ATV5000   68 Pin PLCC Programming adapter for Atmel ATV5000 microcontrollers. Clamshell ZIF Socket For Atmel ATV5000 Plastic PLCC Package Type 68 Pins PLCC to 40 Pin DIP Clamshell ZIF Socket DIP rows are 600 mils apart $180.00 68PL-40D-ZL-PIC16C923   68 Pin PLCC Programming adapter for Microprocessors: PIC16C923, PIC16C924, PIC16C925, PIC16C926 microcontrollers. Auto-eject ZIF Socket For Atmel ATV5000 Plastic PLCC Package Type 68 Pins PLCC to 40 Pin DIP Auto-eject ZIF Socket Staggered DIP rows are 500 and 600 mils apart $180.00 68PL-40D-ZO-PIC17C752 68 Pin PLCC Programming adapter for Microchip PIC17C752 and PIC17C756A microcontrollers. Auto-eject ZIF Socket For Microchip PIC17C752 and PIC17C756A Plastic PLCC Package Type 68 Pins PLCC to 40 Pin DIP Auto-eject ZIF Socket DIP rows are 600 mils apart $180.00 68PL-40D-ZL-AT89C51RD2   68 Pin PLCC Programming adapter for Atmel AT89C51ED2 and AT89C51RD2 microcontrollers. Clamshell ZIF Socket For Atmel AT89C51ED2 and AT89C51RD2 Plastic PLCC Package Type 68 Pins PLCC to 40 Pin DIP Clamshell closed top Socket DIP rows are 600 mils apart $180.00 68PL-40D-ZAL-AT89C51RD2   68 Pin PLCC Programming adapter for Atmel AT89C51ED2 and AT89C51RD2 microcontrollers. Clamshell ZIF Socket For Atmel AT89C51ED2 and AT89C51RD2 Plastic PLCC Package Type 68 Pins PLCC to 40 Pin DIP Auto-eject ZIF Socket DIP rows are 600 mils apart $180.00 68PL-40D-ZAL-DS87C550 68 Pin PLCC Programming adapter for Dallas DS87C550, NXP - Philips P87C552, P87C652 microcontrollers. Clamshell ZIF Socket For Dallas Semiconductor - Maxim IC DS87C550, NXP - Philips P87C552, P87C652 Plastic PLCC Package Type 68 Pins PLCC to 40 Pin DIP Auto-eject ZIF Socket Staggered DIP rows are 500 and 600 mils apart $180.00 68PL-40D-ZL-87C552   68 Pin PLCC Programming adapter for Dallas 87C550, NXP - Philips 87C552 and 87C562 microcontrollers. Clamshell ZIF Socket For Dallas Semiconductor - Maxim IC 87C550, NXP - Philips 87C552 and 87C562 Plastic PLCC Package Type 68 Pins PLCC to 40 Pin DIP Clamshell ZIF Socket Staggered DIP rows are 500 and 600 mils apart $180.00 68PL-40D-ZL-87C592   68 Pin PLCC Programming adapter for NXP - Philips 87C592 microcontroller. Clamshell ZIF Socket For NXP - Philips 87C592 Plastic PLCC Package Type 68 Pins PLCC to 40 Pin DIP Clamshell ZIF Socket Staggered DIP rows are 500 and 600 mils apart $180.00 68PL-40D-ZL-DS87C550   68 Pin PLCC Programming adapter for Dallas 87C550D, NXP - Philips P87C552, P87C652 microcontroller. Clamshell ZIF Socket For Dallas Semiconductor - Maxim IC 87C550D, NXP - Philips P87C552, P87C652 Plastic PLCC J-lead Package Type 68 Pins PLCC to 40 Pin DIP Clamshell ZIF Socket Staggered DIP rows are 500 and 600 mils apart $180.00 Part Number   84 Pin PLCC Programming Adapters    Price Shopping Cart 84PL-40D-ZAL-17C762 84 Pin PLCC ZIF Socket to 40 Pin DIP Programming Adapter for PIC 17C762 & 17C766 For Microchip PIC 17C762 & 17C766 Plastic PLCC Package Type 84 Pins PLCC to 40 Pin DIP Open top ZIF Socket DIP rows are 600 mils apart $218.00
